| PRODUCT | Spectrum Analyzer |
|---|---|
| MODEL | FSC3 |
| PRODUCT SERIES | FSC |
| MANUFACTURER | Rohde and Schwarz |
| DESCRIPTION | 9 kHz to 3 GHz Spectrum Analyzer (Signal Analyzer) |
SHARE ON:
Product Overview
Key Facts
- Frequency range 9 kHz to 3 GHz or 6 GHz
- Resolution bandwidths 10 Hz to 3 MHz
- High sensitivity (< –141 dBm (1 Hz), with optional preamplifier < –161 dBm (1 Hz ))
- High third order intercept (> 10 dBm, typ. 15 dBm)
- Low measurement uncertainty (< 1 dB)
- Internal tracking generator (model .13/.16)
- Compact dimensions
- Low power consumption (12 W)
Features
- Measurement functions
- Easy operation
- Documentation and remote control
Brief Description
The R&S®FSC is a compact, cost-efficient solution that offers all essential features of a professional spectrum analyzer with Rohde & Schwarz quality. It covers a wide range of applications from simple development tasks to production, or can be used for training RF professionals.
