Product Overview

The PNA-X is an integrated vector network analyzer featuring a built-in S-parameter test set, one or two synthesized sources used for device stimulus, a solid-state drive, USB interfaces, and a 12.1” LCD touch screen display. The N5241B, N5242B, and N5249B have 50 ohm, ruggedized 3.5 mm (m) test ports. The N5244B and the N5245B have 50 ohm, ruggedized 2.4 mm (m) test ports. The N5247B has 50 ohm, ruggedized 1.85 mm (m) test ports. Included with each instrument is a mouse, keyboard (U.S. style), a 3-year return-to-Keysight service warranty, and one day of on-site productivity assistance (PS-S20-PNA).

Key Features and Functions

• Simplify your test stations by replacing racks and stacks of equipment
• Increase productivity with the most integrated and flexible single-connection microwave test engine
• Reduce test time with the world’s widest range of single-connection measurement applications
• Accurately test linear and nonlinear device characterization using advanced error correction
• Accelerate insight into component behavior using a multi-touch display and intuitive user interface

Resources

File Resources:

Keysight N5247B 2-Port and 4-Port PNA-X Network Analyzer Data Sheet and Technical Specifications
