Product Overview

The PNA Series of network analyzers offers industry-leading performance for testing amplifiers, mixers and frequency converters. The PNA Series provides a winning combination of excellent hardware and powerful measurement applications to measure a broad range of devices fast and accurately. All models are available in 2-port single-source and 4-port dual-source versions. Pulsed S-parameters are easy using built-in pulse modulators and pulse generators.

Key Features:

• Meet your toughest measurement challenges with the highest performing microwave network analyzer in the industry
• Measure S-parameters with the smallest uncertainty and highest stability
• Efficiently characterize active components with applications that simplify setups
• Meet your specific budget and measurement needs by customizing to just the right level of performance
• Accelerate insight into component behavior using a multi-touch display and intuitive user interface


Highest performance:

• High source output power of +13 dBm at 1 GHz to +11 dBm at 67 GHz
• High dynamic range: 134 dB at 20 GHz at test port
• Low trace noise: 0.002 dB rms at 1 kHz bandwidth
• Low receiver noise floor
• High receiver compression level
• Fast measurement speed: 3.6 to 23 μsec/point
• High stability: < 0.03 dB/°C

Resources

File Resources:

Keysight 2-Port and 4-Port PNA Network Analyzer Data Sheet and Technical Specifications

Keysight PNA Family Microwave Network Analyzers Configuration Guide
