Product Overview

Overview

• Reach for unrivaled excellence in your measurements and designs
• Transform deeper understanding into better designs with the PNA’s outstanding measurement integrity
• Meet your toughest measurement challenges with the highest performing microwave network analyzer in the industry
• Get the best accuracy with Keysight’s S-parameter measurements
• Meet your specific budget and measurement needs by customizing to just the right level of performance


Specifications

• Maximum Frequency: 43.5 GHz
• Dynamic Range: 127 dB
• Output Power: 13 dBm
• Trace Noise: 0.003 dBrms
• Number of Built-In Ports: 2 or 4 ports
• Harmonics: -60 dBc
• Noise Floor: -114 dBm
• Best Speed at 201 Point, 1 Sweep: 5.5 ms
• Network Analyzer Series: PNA High Performance
• Instrument Type: Vector Network Analyzer
• Applications: Balance Measurements
• Components:
  • Antennas
  • Mixers/Frequency Converters
  • Amplifiers
• Benchtop: Yes

Resources

File Resources:

Keysight 2-Port and 4-Port PNA Network Analyzer Data Sheet and Technical Specifications
