Product Overview

Key Features and Functions:

• Signal analysis capabilities with up to 80 MHz analysis bandwidth, +/-0.19 dB absolute amplitude accuracy, -155 dBm DANL, -118 dBc/Hz phase noise at 10 kHz offset, and 81 dB W-CDMA ACLR dynamic range
• Address application-specific requirements with capabilities including 16 measurement personalities and one-button measurement simplicity


Performance:

• +/-0.19 dB absolute amplitude accuracy
• -155 dBm (-168 dBm w/preamp) displayed average noise level (DANL)
• -118 dBc/Hz phase noise at 10 kHz offset
• 81 dB W-CDMA ACLR dynamic range


Analysis bandwidth:

• Standard 10 MHz analysis bandwidth
• Optional 40 or 80 MHz analysis bandwidth to capture and measure complex signals.
• -78 dB (nominal) third order intermodulation for 40 or 80 MHz analysis bandwidth
• Up to 300 MHz analysis bandwidth for calibrated VSA measurements


Flexibility:

• Flexible platform with 16 optional, easy-to-use built-in measurement personalities and hardware options
• PowerSuite enables one-button power measurements for over 20 radio formats PSA PowerSuite
• One-Button Power Measurements
