Keysight Technologies E4981A
| PRODUCT | LCR & Impedance Analyzer |
|---|---|
| MODEL | E4981A |
| PRODUCT SERIES | E4981A |
| MANUFACTURER | Keysight |
| DESCRIPTION | Capacitance Meter LCR Meters and Impedance Analyzer |
SHARE ON:
Product Overview
Product Overview
Key Features & Specifications
Measurement Time
- High speed measurement: 2.3 ms (1 MHz), 3.0 ms (1 kHz), 11.0 ms (120 Hz)
Basic Accuracy
- Accurate C-D testing: 0.07%, 0.0005
More Features
- 9 Bin Sorting
- 256 Multi-channel correction
- Compatible SCPI command and Handler/Scanner interfaces with the 4268A and 4288A
- Test signal level compensation for high value ceramic capacitor tests
- Versatile PC connectivity (LAN, USB and GPIB)
Description
The E4981A capacitance meter offers a high-speed with reliable measurements for ceramic capacitor testing in the production lines. The E4981A realizes the measurement capabilities of capacitance from small to large values with accurate measurements. The E4981A capacitance meter contributes improvements of the test throughput, while attaining excellent component quality for ceramic capacitor testing.
