Product Overview

Key Features and Functions

• Address your toughest requirements with metrology-grade frequency & level accuracy with excellent distortion & spurious characteristics
• Test high-power devices & overcome test system losses with 1 W output power
• Address the demanding needs of Doppler radar, ADC & receiver-blocking tests with the PSG’s extremely low phase noise
• Characterize devices & circuits by adding AM, FM, PM & pulse modulation to your signal
• Meet test system needs up to 1.1 THz with frequency extender modules


What’s Included

• Standard output power
• Standard spectral purity
• CW signal generation
• Amplitude range of +15 to -20 dBm
• 3.5 mm (f) to 3.5 mm (f) connector adapter (20 GHz model only)
• 2.4 mm (f) to 2.4 mm (f) and 2.4 mm (f) to 2.9 mm (f) connector adapters (31.8, 40 & 50 GHz models only)
• 1.85 mm (f) to 1.85 mm (f) and 2.4 mm (f) to 2.9 mm (f) connector adapters (67 GHz model only)
• Country-specific power cord
• Documentation set (CD-ROM)
• 3-year return-to-Keysight warran
